Topring | SKU :
TG132
Standard Duty Desiccant Systems
Prix habituel
$98500 CAD
Prix unitaire
/
Indisponible
Standard Duty Desiccant Systems est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Description
Description
- 3-stage standard duty desiccant system
- The standard duty desiccant system offers the same benefits as the heavy-duty system, but is designed for less frequent use. It is also a 3-stage system engineered to provide high quality air. It removes dirt, water, oil and uncondensed moisture from compressed air lines. Very efficient at protecting expensive and sensitive air tools. Does not require electricity or refrigerants to provide extremely dry compressed air. Silica gel provides maximum absorption, which can be monitored through a small sight glass. When the blue gel turns pink, the gel is then saturated with water and should be replaced with fresh gel to allow the system to remain effective. System consists of a filter (5 microns) with auto drain, coalescing filter (0.1 microns) with auto drain, desiccant dryer, filter/regulator with gauge and a safety slide valve.; SPECIFICATIONS; Max. Working Pressure: 175 PSI; Port Size:1/2" NPT; Air Flow Capacity:20 SCFM; ; 3 STAGE FILTRATION:; 1.Integral filter/regulator removes particulates down to 5 microns in size, to protect the regulator, which then reduces the pressure to the desired pressure setting; 2.Coalescing filter removes 99.99% of oil aerosols and microscopic particles down to 0.1 microns in size; 3.Desiccant dryer removes all remaining water vapour and a 40 micron filter element removes traces of any desiccant dust before it leaves the system
Specifications
Max. PSI
175 PSI
Port Size
1/2" NPT
No. Of Stages
3-Stage
Air Inlet
1/2" NPT
Delivery and Shipping
Delivery and Shipping
- Most products are currently free shipping within Canada, except in some remote areas. Please verify your delivery address to ensure accurate shipping cost information is displayed.
- The delivery date is for reference only and may be adjusted according to the delivery address and available stock.
